History

ACCRE’s predecessors

Vanderbilt’s legacy in high-performance computing goes back to 1962, when a large mainframe was built inside the round building of Stevenson Center. The building was surrounded with glass walls to showcase its state-of-the-art technology. When the building was converted to the Vanderbilt Biomolecular Nuclear Magnetic Resonance Center in 2000, the glass walls were kept in place in the hope that it would become a historic building based on its unique composition.

Question: What is that round building next to Stevenson Center? Answer: It was first built in 1962 to hold a first-generation computer, called a mainframe, which took up the entire building. The computer, with all its blinking lights, was an example of state-of-the-art technology, so the building was built with glass walls to showcase it. In 2000, the building was converted to the Biomolecular Nuclear Magnetic Resonance Center, but “we wanted to try to keep the building because we were speculating that it was so unique that it would one day be a historic building,” said Judson Newbern, associate vice chancellor of campus planning and construction. “We wanted to keep the composition of the building.” And so, in order to put in the NMR magnets, “we kept the sides of the building, cut the top off, dropped the magnets in and built the roof again,” Newbern said. Campus architects also designed part of Stevenson to match the round building. “We took the design of the chemistry building and curved the side to pick up the curve of the NMR center,” Newbern said.
Article about the Stevenson Center mainframe in the Vanderbilt Hustler, Dec 12, 2007. (source)

The vision for ACCRE originated with the VUPAC cluster built in 1994 and expanded over the years by Vanderbilt physicists. By the end of its life as a useful production facility, VUPAC was a cluster of roughly 50 workstations loosely coupled together to provide a (very coarse) parallel computing environment.

In the late 1990s, Paul Sheldon in Physics and Astronomy joined forces with Jason Moore in Human Genetics and spearheaded the building of the VAnderbilt MultiProcessor Integrated Research Engine (VAMPIRE). VAMPIRE was a 55-node Linux cluster first put into service in July 2001 with assistance from ITS. Alan Tackett, a computational theoretical physicist, was brought on board to provide technical expertise and vision. VAMPIRE was intended to be a proof-of-concept project. It proved that many groups from diverse disciplines with differing compute problems can equitably share a cluster. This first shared cluster allowed many issues to be resolved, including the type of software to ensure equitable sharing, correct installation of the operating system, system maintenance for a large number of nodes, how to ensure the hardware works properly and how to monitor all the nodes.

Will Johns, Ph.D., Jason Moore, Ph.D., and Paul Sheldon, Ph.D. (Photo: Dana Johnson, VUMC Reporter)

VAMPIRE was successful: numerous publications resulted from calculations performed with the cluster and cross-fertilization between the disciplines was even greater than anticipated. VAMPIRE could no longer provide enough computing for the needs of all the researchers involved. While efforts to secure funding for a much larger compute cluster continued, funding from many researchers, but primarily from Ron Schrimpf and Peter Cummings in the School of Engineering, provided funding for the next generation of the compute cluster: a 120-node Linux cluster purchased in 2003, which remained in service until March 2008.

ACCRE is established

With the success of VAMPIRE and the support of a large group of researchers, the proposal for the entity now known as ACCRE was submitted to the Academic Venture Capital Fund of Vanderbilt University. An $8.3 million grant was received to transform the cluster into a University-wide resource capable of meeting the needs of any researcher on campus. The scope of the operation was expanded from a compute cluster to also include data storage and data visualization capabilities. Funding was secured in late 2003 and planning begun to establish the physical infrastructure and personnel for this task.

Rogues Exposed by Kara Furlong and David F. Salisbury. Research by Assistant Professor of Astronomy Kelly Holley-Bockelmann indicates that there may be hundreds of nearly impossible-to-spot black holes careening around the galaxy. Because these rogue black holes can’t be directly observed, Holley-Bockelmann’s research simulates their behavior. She uses the supercomputer at Vanderbilt’s Advanced Computing Center for Research and Education (ACCRE) to run simulations to test her theories. Her research proposes that the merger of two black holes that are rotating at different speeds (or are different sizes) produces a big kick, pushing the newly merged black hole away in an arbitrary direction at velocities as high as 4,000 kilometers per second. “This is much higher than anyone predicted,” the astronomer says. If the roughly 200 globular clusters in the Milky Way have indeed spawned black holes, this means that hundreds of them are probably wandering invisibly around the Milky Way, waiting to engulf the nebulae, stars and planets unfortunate enough to cross their paths. Fortunately, the existence of a few rogue black holes in the neighborhood does not present a major danger. “These rogue black holes are extremely unlikely to do any damage to us in the lifetime of the universe,” Holley-Bockelmann stresses. “Their danger zone is really tiny, only a few hundred kilometers.” Holley-Bockelmann said to think of her findings this way: “What I do on a day-today basis is try to figure out what the link is between a galaxy and the black hole that lives within it. Does it change the shape of the galaxy in any way? Does it affect the way the galaxy moves and evolves and ultimately dies? My job is to figure out how the black hole and the galaxy communicate with one another.” Holley-Bockelmann presented the research, which was conducted in collaboration with scientists at Penn State University and the University of Michigan, at a meeting of the American Astronomical Society.
Article in the Vanderbilt Arts and Science magazine, Spring 2009. Photo by John Russell. (source)

AVCF funding allowed the staff to be expanded so that the compute cluster services could be offered to all Vanderbilt researchers. New services were added including a helpdesk system called Request Tracker, evening and weekend on-call assistance for problems impacting the entire cluster, daily office hours, and training workshops. Also added was educational use of the cluster for Vanderbilt classes and guest accounts for new Vanderbilt-affiliated researchers as a way to test out usage of the cluster.

AVCF funds were also used to begin expanding the cluster in Spring 2004 but most cluster expansion has been the result of researcher funding through grants and faculty start-up packages.  The first major expansion of the compute cluster for ACCRE began in August 2004, approximately five years after the VAMPIRE cluster began when an NIH compute grant was successfully secured to provide extensive computing capacity for NIH-funded researchers in the School of Medicine. Hardware for that grant as well as for a second NIH grant secured in 2008  was purchased under the leadership of Dave Piston.

During this same period, ACCRE began operating as a Core Center under the VUMC Office of Research and developed a funding mechanism that allowed for hardware contributions through annual payments in addition to the hardware additions by grants and start-up packages.

Expanding storage

The focus of ACCRE was also expanded beyond computing beginning in 2004.  To meet the needs of Vanderbilt researchers not met by off-the-shelf storage solutions, ACCRE staff began the process of developing in-house a new distributed storage system.  Called LStore, the new system provides a flexible logistical storage framework for distributed, scalable, and secure access to data for a wide spectrum of users. Vanderbilt research groups began using this storage system as early beta testers in January 2007 and the system began being used in 2010 for a major Physics collaboration.

The cluster filesystem was also substantially increased starting in 2010 to meet the needs of researchers for disk space connected to the cluster and currently over 800 TB are in use by researchers.  The size of the filesystem can be adjusted to meet researcher demand.

Since 2011 Vanderbilt has served as a Tier 2 CMS institution. CMS (Compact Muon Solenoid) is one of two primary detectors at the Large Hadron Collider located in Switzerland. Vanderbilt currently hosts 4 petabytes of storage (i.e., 4,000 terabytes) in support of this project alone, all of which is stored in LStore along with over 300 terabytes of video data from the Vanderbilt Television News Archive (TVNA) located in the Jean and Alexander Heard Library.

REDDnet

Overlapping with the development of LStore, a wide area storage network called the Research and Education Data Depot Network (REDDnet) was launched in 2006 to support data-intensive collaboration among researchers who are distributed across Internet 2 and other research networks.

ACCRE today

The cluster is currently composed of over 7,000 cores in over 600 compute nodes. Also included are a group of GPU nodes each containing 4 high end Nvidia GPU cards. New hardware continues to be added to the cluster based on contributions from researchers as required to meet their computing needs.
